name: F17 Grade FORMPLY
about:

  Linyi Foryou International have been engaged in wood since 2008, and is located in Linyi City,Shandong Province,China - the biggest and famous wood production centre in China . We are mainly specialized in the business of manufacturing and exporting ...




DETAIL



Our company is one of the leading F14/F17 Formply plywood exporter in China. Our factory has full certifactes of F17 stress-grade film faced plywood, we have ventured in the Australia standard plywood with a lot of effort. Our experience and technique enable us to produce excellent quality formply complying with AS 6669 for the Australian building industry.


F17 Formply, F14 Formply – Australian Standard Formwork Plywood

Size: 1200x1800x17mm, 1200x2400x17mm
Core: Hardwood
Film: Phenolic Coated Film, Black Color
Bond: A Grade Phenolic Resin
Formaldehyde: Super E0
Product Origin: China
Standard: AS6669 Formwork Plywood Standard


17 Formply Quality

F17 Formply is made of a high-density overlay (HDO) of phenolic resin impregnated paper bonded to plywood. It has a tested stress grade of F17. The panel is ideal for concrete formwork and structural uses. The phenolic overlay helps to protect the hardwood face as well providing a clean and smooth surface for the poured concrete.

Our production selects the best hardwood veneers, phenolic A-bond and phenolic coated overlay film for making excellent sheets.

F17 Formply has been developed specifically for Australian conditions. Made from mixed veneers including a hardwood eucalyptus core, poplar face veneers and a phenolic film overlay, it delivers superior results.

Independently certified and carrying the Benchmark Product Certification Mark to AS 6669-2016 under the internationally recognized JAS-ANZ accredited quality control program, it is ideal for general formwork such as decks, pre-cast, and tilt-up panel construction.

Rigorous quality testing ensures its durability and allows for multiple uses of one panel. This, plus its wide application, saves on material management costs.


Product Features

· High Strength meeting F17 Stress Grade

· Excellent Squareness and Size Tolerance

· Waterproof seal on edges of each sheet to keep humid off the panel

· Can obtain a Class 2 finish with the first pour


F17 Formply Sizes

We offer two sizes F17 Grade film faced plywood complying with AS6669:2016 standard.

· 1200x1800x17mm

· 1200x2400x17mm



Competitive Advantages

Our production engineers have total knowledge in phenolic plywood production. We can control the product quality in detail.

Formply is manufactured from wood veneers glued with synthetic adhesives and overlayed with phenolic impregnated papers (also called phenolic surface films or ‘plastic face’). With the right care you can extend the life of your Formply by:


STORAGE

· Storing panels undercover, on levelled ground

· Never wrapping panels in plastic

· Protecting panels from prolonged contact with water. The phenolic surface is water resistant, not water proof and excess moisture will cause swelling and board twist

· Storing the panels away from direct sunlight. Excess exposure to sun, heat and dry weather will induce warp, twist, drying and shrinking to the upper surface


PREPARATION

· While panels are delivered with all edges covered in edge paint to reduce moisture penetration, if panels are cut or drilled all new edges must be resealed with a suitable acrylic-based paint prior to pouring

· Use a release agent to reduce water absorption and assist in the stripping of formwork

· Fill gaps between veneers with putty and seal edges

· Fasten panels from the back to avoid surface damage

· Inspect decks prior to pouring, with any distorted sheets likely to cause surface imperfections nailed and screwed flat


AFTER USE

· Clean panels carefully, using plastic or nylon tools to avoid damage

· Use soapy water to de-grease the surface

· Repair small scratched with a suitable mastic

· Fill deeper scratches, nail and screw holes with a mastic or epoxy filler
